11
Control elements
1
4
526
73
Throttle lever (1)
With the accelerator lever, you change the
engine speed and thus control the engine
output.
1 2
1:
Neutral position
2:
Full throttle
Drive lever (2)
With the drive lever, you switch the drive on
and off.
Drive on (I):
Press the lever towards
the handlebar and
continue to hold.
Drive off (0):
Release the lever.
Engine brake bar (3)
The engine brake bar is a protective device.
When you release the bar, the engine is shut
off immediately, the blade comes to a
standstill within 3 seconds.
M
I
0
Blade/engine on (I):
Press
the lever towards the
handlebar and continue to
hold.
Blade/engine off (0):
Release the lever.
Lever for lateral adjustment of
handlebar (4)
1. Release the eccentric tension lever.
2. Attention: Do not crush the Bowden
cables when pivoting the handlebar.
Swivel the handlebar to the side to the
desired position.
3. Clamp the handlebar with the eccentric
tension lever.
Vario lever (5)
With the vario lever, you can continuously
adjust the speed of the device while the
engine is running.
MIN:
= slow
MAX:
= fast
Rear brake lever (6)
The brake is required for going downhill and
storing the device.
1
Brake on (I):
Press the lever
towards the
handlebar and
continue to hold.
Brake off (0):
Release the lever.
Parking brake on (I):
Press the lever
towards the
handlebar and press
the notch (1).
