15
1
The cutting height can be adjusted on each
axle in 6 levels of 30 mm up to 100 mm.
1. Switch off the engine and wait until the
blade has come to a standstill.
2. Unlock the grip bar at the front axle by
pressing the touch handle (
1).
3. Swivel the grip bar to the desired
position.
4. Set the cutting height at the rear axle in
the same way.
Starting
Danger!
During startup, there is a risk of
injury caused by the rotating blade.
Make sure that no one is within the
danger zone of the blade. Do not
tip the device over to one side
during startup.
Danger!
If after startup the carburetor does
not close properly, fuel will
overflow and a fire hazard occurs.
Close the fuel valve and contact an
authorised service centre.
Starting the device
1. Place the device onto a flat surface, not
in high grass.
2. Open the fuel valve and the tank
ventilation.
3. Plug on the spark plug connector.
4. Only for cold start: Close the choke at the
carburetor (turn anti-clockwise).
5. Press the tickler at the carburetor until
the fuel is seen to drip.
6. Put the accelerator lever to lowest engine
speed position.
7. Actuate and hold the engine brake lever.
8. Pull the starter point slowly out until you
feel resistance then pull out quickly –
engine starts to run.
9. Let the starter rope retract slowly.
10. Put the accelerator lever to medium
engine speed position.
11. Reopen the choke (turn clockwise).
12. For mowing, set the accelerator lever to
the maximum speed.
Driving
Driving
In case of a dangerous situation, switch off
the blade by releasing the engine brake lever.
While driving forward, all four wheels are
driven.
Drive on:
1. Press the drive lever towards the
handlebar – device is running.
Drive off:
1. Release the drive lever.
