Page B-1
B
Specifications
FriendlyNet Ethernet Hub Specifications
IEEE 802.3 Compliance
❏ 10Base-T
Network Interface and Cable Specifications
❏ RJ-45 port: five or eight connectors for use with
10Base-T cabling
Maximum Segment Lengths
❏ 10Base-T (UTP): 100 meters maximum
(24 AWG recommended)
LED Indicators
❏ Unit: Power and Collision
❏ 10Base-T ports: Link/Activity
Physical Dimensions
❏ 8-port Hub: 145mm x 78mm x 26mm (L x W x H)
❏ 5-port Hub: 100mm x 78mm x 26mm (L x W x H)
Environment
❏ Temperature
❏ Operating: 0° C to +50° C
❏ Storage: -20° C to +70° C
