Page 2-1
2
Installation
Before You Start
▲
Important:
Check the AC power line voltage
used in your area. The AC power adapter
included with your hub must match the power
supply voltage used in your area.
❏
AC input power
: equal to the AC power
voltage used in your area
❏
DC output power
: 5V 800mA
Installation Overview
Before you connect the FriendlyNet Hub to other devices, review
the following guidelines:
❏
Make sure the network cable length is
less than
100 meters
.
❏
Use a
straight-through
twisted pair wire.
❏
When connecting two hubs together (cascading
hubs), make sure the primary hub’s IN port is
connected to the secondary hub’s UPLINK port.
❏
Network cable segments can be connected to, or
disconnected from, the FriendlyNet Hub while
the power is on.
∆
Note:
The installation diagrams in this section
pertain to both the 5-port and 8-port FriendlyNet
Hub.
