Introduction
Introducing the FriendlyNet Ethernet Hub
Thank you for purchasing the Asanté FriendlyNet 5-port or 8-port
Ethernet Hub.
The FriendlyNet Hub provides your network with up to 5 or 8
Unshielded Twisted Pair (UTP) port connections.
5-port FriendlyNet Hub
The 5-port FriendlyNet Hub (FH10T5) comes with five RJ-45 ports
for connecting to 10Base-T network stations and one UPLINK
(cascade) port for connecting to another hub.
Figure 1-1 5-port FriendlyNet Hub, front and rear views
8-port FriendlyNet Hub
The 8-port FriendlyNet Hub (FH10T8) comes with eight RJ-45
ports for connecting to 10Base-T network stations and one
UPLINK (cascade) port for connecting to another hub.
Figure 1-2 8-port FriendlyNet Hub, front and rear views
5-port HUB
12345
5Vdc
Power Socket
Pwr
Col
Link/Act.
Cascade Port
RJ-45 10Base-T Ports
Uplink 12345
Power Socket
8-port HUB
5Vdc
Link/Activity
1234
Pwr
Col
5678
Uplink
18765432
Cascade Port
RJ-45 10BASE-T Ports
