ASCOM d62 Talker Configuration Manual

TD 92639EN
31 October 2013 / Ver. J
Configuration Manual
Ascom d62 DECT Handset
6
2.2.1 Via Chargers
• Connect a DC4 desktop charger or a CR3 rack charger via th
e Ethernet port to the
network.
The charger is by default configured to connect to th
e network using DHCP. If DHCP is not
used in the network, connect each charger via USB to PDM and configure a static IP
address.
• Start the Device Manager.
• Place the handset in a charger that is connected to the Device Manager. The handset can
either b
e turned off or
turned on when placing it in the charger. A handset that is turned
off starts up automatically and the battery charging symbol is displayed.
Figure 2.
Client
IP
Device Manager
Unite module
Figure 2. Configuration of handsets via Device Manager and chargers.
2.2.2 Over-the-Air via IP-DECT
There is no external equipment needed besides Device Manager and IP-DECT. Please proceed
to cha
pter 3 Handset Maintenance on page
8.
Figure 3.
Client
IPBS
Ascom
IP-DECT
System
IP
Device Manager
Unite module
Figure 3. Configuration of handsets via Device Manager and over-the-air.
