PRELIMINARY
Alarm Operation
USER MANUAL
Ascom i63 VoWiFi Handset
6 Alarm Operation
Applicable to Protector only.
If a shared phone is used, it must be logged in to the system to be able to send alarm. See 3.4 Log a Shared
Phone On and Off, page 14.
If two or more alert notifications of equal priority are generated, the one generated first is
displayed first.
Recognition of alerts, warnings, and conversation messages can be impeded if the volume of the sounds
used to indicate alerts, warnings, and conversation messages is lower than the ambient sound levels.
Table 1 Alarm Sound Pressure Levels
Sound pressure level range for medium priority
alarm (one beep):
Measured according to IEC 60601-1-8.
44 dB–80 dB, adjustable in 8 steps.
Sound pressure level range for high priority alarm
(siren):
Measured according to IEC 60601-1-8.
46 dB–81 dB, adjustable in 8 steps.
6.1 Push-button Alarm
Press the alarm button twice within two seconds to activate the alarm. An information text is displayed,
default Personal Alarm is displayed. The alarm is sent to the alarm central that distributes it further. After
that the handset returns to stand-by mode.
It is always possible to trigger the alarm when speaking, editing the settings, or while the handset is locked.
6.2 Acoustic Location Signal
An alarm can be followed by an Acoustic Location Signal (ALS). The ALS is a signal from the handset that
sounds for a predefined period of time. The signal is silenced by pressing the Mute button on the handset.
6.3 Test Alarm
Press and hold the alarm button until the information text is displayed. As default, Test Alarm is displayed.
6.4 Man-down and No-movement Alarm
Applicable to Protector only.
The handset version must be WH2-AAAA/2A or above (see label under battery cover). These functions
require a license.
43 TD 93289EN / / Ver.
