Ascon Tecnologic - K Series - ENGINEERING MANUAL -Vr. 9.0 PAG. 28

]

Out Group (Outputs Parameters)

no.

Para-

meter

Description Dec. Range Default

Vis.

Promo.

12 o1F Out 1 function 0

NonE = Output not used,

H.rEG = Heating output

c.rEG = Cooling output

AL = Alarm output

t.out = Timer output

t.HoF = Timer output OFF when timer in hold

P.End = Program end indicator

P.HLd = Program hold indicator

P. uit = Program wait indicator

P.run = Program run indicator

P.Et1 = Program Event 1

P.Et2 = Program Event 2

or.bo = Out-of-range or burn out indicator

P.FAL = Power failure indicator

bo.PF =

Out-of-range, burn out and Power failure indicator

diF.1 = The output repeats the digital input 1 status

diF.2 = The output repeats the digital input 2 status

St.bY = Stand by status indicator

on = Out 1 forced to ON

H.reg A-16

13 o1AL Alarms linked up with the out 1 0

0... 31:

+1 = Alarm 1

+2 = Alarm 2

+4 = Alarm 3

+8 = Loop break alarm

+ 16 = Sensor break (burn out)

AL1 A-17

14 o1Ac Out 1 action 0

dir = Direct action

rEU = Reverse action

dir.r = Direct with reversed LED

ReU.r = Reverse with reversed LED

dir C-0

15 o2F Out 2 function 0

NonE = Output not used
