Ascon Tecnologic - K Series - ENGINEERING MANUAL -Vr. 9.0 PAG. 29
no.
Para-
meter
Description Dec. Range Default
Vis.
Promo.
18 o3F Out 3 function 0
NonE = Output not used
H.rEG = Heating output
c.rEG = Cooling output
AL = Alarm output
t.out = Timer output
t.HoF = Timer output OFF when timer in hold
P.End = Program end indicator
P.HLd = Program hold indicator
P. uit = Program wait indicator
P.run = Program run indicator
P.Et1 = Program Event 1
P.Et2 = Program Event 2
or.bo = Out-of-range or burn out indicator
P.FAL = Power failure indicator
bo.PF =
Out-of-range, burn out and Power failure indicator
diF.1 = The output repeats the digital input 1 status
diF.2 = The output repeats the digital input 2 status
St.bY = Stand by status indicator
on = Out 3 forced to ON
AL A-22
19 o3AL Alarms linked up with the out 3 0
0... 31:
+1 = Alarm 1
+2 = Alarm 2
+4 = Alarm 3
+8 = Loop break alarm
+ 16 = Sensor break (burn out)
AL2 A-23
20 o3Ac Out 3 action 0
dir = Direct action
rEU = Reverse action
dir.r = Direct with reversed LED
ReU.r = Reverse with reversed LED
dir C-0
21 o4F Out 4 function 0
NonE = Output not used
H.rEG = Heating output
c.rEG = Cooling output
AL = Alarm output
t.out = Timer output
t.HoF = Timer output OFF when timer in hold
P.End = Program end indicator
P.HLd = Program hold indicator
P. uit = Program wait indicator
P.run = Program run indicator
P.Et1 = Program Event 1
P.Et2 = Program Event 2
or.bo = Out-of-range or burn out indicator
P.FAL = Power failure indicator
bo.PF =
Out-of-range, burn out and Power failure indicator
diF.1 = The output repeats the digital input 1 status
diF.2 = The output repeats the digital input 2 status
St.bY = Stand by status indicator
on = Out 4 forced to ON
AL A-24
22 o4AL Alarms linked up with the out 3 0
0... 31:
+1 = Alarm 1
+2 = Alarm 2
+4 = Alarm 3
+8 = Loop break alarm
+ 16 = Sensor break (burn out)
AL2 A-25
23 o4Ac Out 3 action 0
dir = Direct action
rEU = Reverse action
dir.r = Direct with reversed LED
ReU.r = Reverse with reversed LED
dir C-0
