Ascon Tecnologic - K Series - ENGINEERING MANUAL -Vr. 9.0 PAG. 31
]
AL3 Group (Alarm 3 Parameters)
no.
Para-
meter
Description Dec. Range Default
Vis.
Promo.
40 AL3t Alarm 3 type 0
nonE = Alarm not used
LoAb = Absolute low alarm
HiAb = Absolute high alarm
LHAb = Absolute band alarm
SE.br = Sensor break
LodE = Deviation low alarm (relative)
HidE = Deviation high alarm (relative)
LHdE = Relative band alarm
nonE C-0
41 Ab3 Alarm 3 function 0
0... 15:
+1 = Not active at power ON
+2 = Latched alarm (manual reset)
+4 = Acknowledgeable alarm
+8 = Relative alarm not active at set point change
0 C-0
42 AL3L
- For High and low alarms, it is the low
limit of the AL3 threshold
- For band alarm, it is low alarm th-
reshold
dP From -1999 to AL3H ( E.U.) -1999 C-0
43 AL3H
- For High and low alarms, it is the
high limit of the AL3 threshold
- For band alarm, it is high alarm
threshold
dP From AL3L to 9999 (E.U.) 9999 C-0
44 AL3 Alarm 3 threshold dP From AL3L to AL3H (E.U.) 0 C-0
45 HAL3 Alarm 3 hysteresis dP 1... 9999 (E.U.) 1 C-0
46 AL3d Alerm 3 delay dP From 0 (oFF) to 9999 (s) oFF C-0
47 AL3o
Alarm 3 enabling during Stand-by
mode
0
0 = Never
1 = During stand by
2 = During overrange and underrange
3 = During overrange, underrange and stand-by
no C-0
]
LbA Group (Loop Break Alarm Parameters)
no.
Para-
meter
Description Dec. Range Default
Vis.
Promo.
48 LbAt LBA time 0 From 0 (oFF) to 9999 (s) oFF C-0
49 LbSt
Delta measure used by LBA during Soft
start
dP From 0 (oFF) to 9999 (E.U.) 10 C-0
50 LbAS Delta measure used by LBA dP 1... 9999 ( E.U.) 20 C-0
51 LbcA Condition for LBA enabling 0
uP = Active when Pout = 100%
dn = Active when Pout = -100%
both = Active in both cases
both C-0
]
rEG Group (Control parameters)
no.
Para-
meter
Description Dec. Range Default
Vis.
Promo.
52 cont Control type 0
Pid = PID (heat and/or cool)
On.FA = ON/OFF asymmetric hysteresis
On.FS = ON/OFF symmetric hysteresis
nr = Heat/Cool ON/OFF control with neutral zone
Pid A-25
53 Auto Autotuning selection 0
-4 = Oscillating auto-tune with automatic restart at
power ON and after all set point change
-3 = Oscillating auto-tune with manual start
-2 = Oscillating auto-tune with auto-matic start at the
first power ON only
-1 = Oscillating auto-tune with auto-matic restart at
every power ON
0 = Not used
1 = Fast auto tuning with automatic restart at every
power ON
2 = Fast auto-tune with automatic start at the first
power ON only
3 = FAST auto-tune with manual start
4 = FAST auto-tune with automatic restart at power
ON and after a set point change
2 C-0
54 Aut.r Manual start of the Autotuning 0
oFF = Not active
on = Active
oFF A-26
55 SELF Self tuning enabling 0
YES = Active
no = Not active
no C-0
