Ascon Tecnologic - K Series - ENGINEERING MANUAL -Vr. 9.0 PAG. 32
no.
Para-
meter
Description Dec. Range Default
Vis.
Promo.
56 HSEt Hysteresis of the ON/OFF control dP 0... 9999 ( E.U.) 1 A-27
57 cPdt Time for compressor protection 0 From 0 (oFF) to 9999 (s) oFF C-0
58 Pb Proportional band dP 0... 9999 (E.U.) 50 A-28
59 int Integral time 0 From 0 (oFF) to 9999 (s) 200 A-29
60 dEr Derivative time 0 From 0 (oFF) to 9999 (s) 50 A-30
61 Fuoc Fuzzy overshoot control 2 0.00... 2.00 0.50 A-31
62 H.Act Heating output actuator 0
SSr = SSR
rELY = Relay
SLou = Slow actuators
SSr A-32
63 tcrH Heating output cycle time 1 0.1... 130.0 (s) 20.0 C-0
64 PrAt
Power ratio between heating and cool-
ing action
2 0.01... 99.99 1.00 A-34
65 c.Act Cooling output actuator 0
SSr = SSR
rELY = Relay
SLou = Slow actuators
SSr A-35
66 tcrc Cooling output cycle time 1 0.1... 130.0 (s) 20.0 C-0
67 rS Manual reset (Integral pre-load) 1 -100.0... 100.0 (%) 0.0 C-0
68 od Delay at power ON 2 From 0.00 (oFF) to 99.59 (hh.mm) oFF C-0
69 St.P
Maximum power output used during
soft start
0 -100... +100 (%) 0 C-0
70 SSt Soft start time 2 From 0.00 (oFF) to 8.00 (inF) (hh.mm) oFF C-0
71 SStH Threshold for soft start disabling dP -1999... +9999 (E.U.) 9999 C-0
]
SP Group (Set Point Parameters)
no.
Para-
meter
Description Dec. Range Default
Vis.
Promo.
72 nSP Number of used set points 0 1... 4 1 A-38
73 SPLL Minimum set point value dP From -1999 to SPHL -1999 A-39
74 SPHL Maximum set point value dP From SPLL to 9999 9999 A-40
75 SP 1 Set point 1 dP From SPLL to SPLH 0 O-41
76 SP 2 Set point 2 dP From SPLL to SPLH 0 O-42
77 SP 3 Set point 3 dP From SPLL to SPLH 0 O-43
78 SP 4 Set point 4 dP From SPLL to SPLH 0 O-44
79 SPAt Selection of the active set point. 0 From 1 (SP 1) to nSP 1 O-45
80 SP.rt Remote set point type 0
RSP = The value coming from serial link is used as
remote set point
trin = The value will be added to the local set point
selected by SPAt and the sum becomes the
operative set point
PErc =
The value will be scaled on the input range
and this value will be used as remote set point
trin C-0
81 SP.Lr Local/remote set point selection 0
Loc = local
rEn = remote
Loc C-0
82 SP.u
Rate of rise for POSITIVE set point change 2 0.01... 100.00 (inF) Engineering units per minute inF C-0
83 SP.d Rate of rise for NEGATIVE set point change 2 0.01... 100.00 (inF) Engineering units per minute inF C-0
