Ascon Tecnologic - K Series - ENGINEERING MANUAL -Vr. 9.0 PAG. 33
]
Tin Group (Timer Function Parameters)
no.
Para-
meter
Description Dec. Range Default
Vis.
Promo.
84 tr.F Independent timer function 0
NonE = Timer not used
i.d.A = Delayed start timer
i.uP.d = Delayed start at power ON
i.d.d = Feed-through timer
i.P.L = Asymmetrical oscillator with start in OFF
i.L.P = Asymmetrical oscillator with start in ON
nonE A-62
85 tr.u Timer unit 0
hh.nn = Hours and minutes
nn.SS = Minutes and seconds
SSS.d = Second and tenth of seconds
nn.SS A-63
86 tr.t1 Time 1
2 00.01... 99.59 when tr.u < 2
1.00 A-64
1 000.1... 995.9 when tr.u = 2
87 tr.t2 Time 2
2 When tr.u < 2: From 00.00 (oFF) to 99.59 (inF)
1.00 A-65
1 When tr.u = 2: From 000.0 (oFF) to 995.9 (inF)
88 tr.St Timer status 0
rES = Timer reset
run = Timer run
HoLd = Timer hold
rES C-0
]
PrG Group (Programmer Function Parameters)
no.
Para-
meter
Description Dec. Range Default
Vis.
Promo.
89 Pr.F Program action at power ON 0
nonE =
Programmer not used
S.uP.d = Start at power ON, first step in stand-by
S.uP.S = Start at power ON
u.diG = Start at Run command detection only
u.dG.d = Start at Run command
, first step in stand-by
nonE A-67
90 Pr.u Engineering unit of the soak 2
hh.nn = Hours and minutes
nn.SS = Minutes and seconds
hh.nn A-68
91 Pr.E
Instrument behaviour at the end of
the program execution
0
cnt = Continue
SPAt = Go to the set point selected by SPAt
St.by = Go to stand-by mode
SPAt A-71
92 Pr.Et Time of the end program indication 2 From 0.00 (oFF) to 100.00 (inF) minutes and seconds oFF A-72
93 Pr.S1 Set point of the first soak dP From SPLL to SPHL 0 A-73
94 Pr.G1 Gradient of the first ramp 1 0.1... 1000.0 (inF= Step transfer) Eng. Unit/minute inF A-74
95 Pr.t1 Time of the first soak 2 0.00... 99.59 0.10 A-75
96 Pr.b1 Wait band of the first soak dP From 0 (oFF) to 9999 (E.U.) oFF A-76
97 Pr.E1 Events of the first group 2 00.00... 11.11 00.00 C-0
98 Pr.S2 Set point of the second soak dP OFF or from SPLL to SPHL 0 A-78
99 Pr.G2 Gradient of the second ramp 1 0.1... 1000.0 (inF= Step transfer) Eng. Unit/minute inF A-79
100 Pr.t2 Time of the second soak 2 0.00... 99.59 0.10 A-80
101 Pr.b2 Wait band of the second soak dP From 0 (oFF) to 9999 (E.U.) oFF A-81
102 Pr.E2 Events of the second group 2. 00.00... 11.11 00.00 C-0
103 Pr.S3 Set point of the third soak dP OFF or from SPLL to SPHL 0 A-83
104 Pr.G3 Gradient of the third ramp 1 0.1... 1000.0 (inF = Step transfer) Eng. Unit/minute inF A-84
105 Pr.t3 Time of the third soak 2 0.00... 99.59 0.10 A-85
106 Pr.b3 Wait band of the third soak dP From 0 (oFF) to 9999 (E.U.) oFF A-86
107 Pr.E3 Events of the third group 0 00.00... 11.11 00.00 C-0
108 Pr.S4 Set point of the fourth soak dP OFF or from SPLL to SPHL 0 A-88
109 Pr.G4 Gradient of the fourth ramp 1 0.1... 1000.0 (inF = Step transfer) Eng. Unit/minute inF A-89
110 Pr.t4 Time of the fourth soak 2 0.00... 99.59 0.10 A-90
111 Pr.b4 Wait band of the fourth soak dP From 0 (oFF) to 9999 (E.U.) oFF A-91
112 Pr.E4 Events of the fourth group 0 00.00... 11.11 00.00 C-0
113 Pr.St Program status 0
rES = Program reset
run = Program start
HoLd = Program hold
0 C-0
