Ascon Tecnologic - K Series - ENGINEERING MANUAL -Vr. 9.0 PAG. 34
]
PAn Group (HMI Operator Parameters)
no.
Para-
meter
Description Dec. Range Default
Vis.
Promo.
114 PAS2 Password level 2 0 From 0 (oFF) to 999 20 A-93
115 PAS3 Password level 3 0 3... 999 30 C-0
116 uSrb
button function during run time
0
nonE = Not used
tunE = Starts auto tuning functions
oPLo = Manual mode (oPLo)
AAc = Alarm reset
ASi = Alarm acknowledge
chSP = Sequential set point selection
St.by = Stand-by mode
Str.t = Run/hold/reset timer
P.run = Program start
P.rES = program reset
P.r.H.r = Run/hold/reset program
nonE A-94
117 diSP Secondary display management 0
nonE = Standard display
Pou = Power output
SPF = Final set point
Spo = Operative set point
AL1 = Alarm 1 threshold
AL2 = Alarm 2 threshold
AL3 = Alarm 3 threshold
Pr.tu = Program time up
Pr.td = Program time down
P.t.tu = Program total time up
P.t.td = Program total time down
ti.uP = Timer time up
ti.du = Timer time down
PErc = Percent of the power output used during soft
start (when the soft start time is equal to in-
finite, the limit is always active; can be used
also when ON/OFF control is selected)
nonE A-95
119 FiLd Filter on the displayed value 1 From 0 .0 (oFF) to 20.0 oFF C-0
120 dSPu Status of the instrument at power ON 0
AS.Pr = Starts in the same way it was prior to the
power down
Auto = Starts in Auto mode
oP.0 = Starts in manual mode with a power output
equal to zero
St.bY = Starts in stand-by mode
AS.Pr C-0
121 oPr.E Operative mode enabling 0
ALL = All
Au.oP = Autp or manual (oPLo) only
Au.Sb = Auto and Stand by only
ALL C-0
122 oPEr Operative mode selection 0
Auto = Automatic
oPLo = Manual
St.by = Stand-by
Auto O-1
]
Ser Group (Serial link Parameters)
no.
Para-
meter
Description Dec. Range Default
Vis.
Promo.
123 Add Address 0
0 (oFF)
1... 254
1 C-0
124 bAud Baud rate 0
1200
2400
9600
19.2
38.4
9600 C-0
125 trSP
Selection of the value to be retransmit-
ted (Master)
0
nonE = Not used
rSP = Operative set point
PErc = Current power output (%)
nonE C-0
