7 PROGRAMMABLE PARAMETERS TABLE
Here below is a description of all the parameters available on the instrument. Some of them may not be present because
depend on the model/type of instrument.
S. - Set Point parameters
Parameter Description Range Default Note
1
S.LS
Minimum Set Point -99.9 ÷ S.HS -50.0
2
S.HS
Maximum Set Point S.LS ÷ 999 99.9
3
SP
Set Point S.LS ÷ S.HS 0.0
i - Inputs parameters
Parameter Description Range Default Note
4
i.SE
Probes Type
Pt PTC;
nt NTC.
nt
5
i.uP
Unit of measurement and resolution
(decimal point)
C0 °C resolution 1°;
F0 °F resolution 1°;
C1 °C resolution 0.1°;
F1 °F resolution 0.1°.
C1
6
i.Ft
Measurement filter oF/0.1 ÷ 20.0s 2.0
7
i.C1
Pr1 Probe Calibration -30.0 ÷ +30.0°C/°F 0.0
r. - Temperature control parameters
Parameter Description Range Default Note
8
r.d
Differential (Hysteresis) 0.0 ÷ 30.0°C/°F 2.0
9
r.t1
Output activation time for probe error
oF/0.01 ÷ 9.59 (min.s) ÷99.5 (min.s x 10) oF
10
r.t2
Output deactivation time for probe error oF/0.01 ÷ 9.59 (min.s) ÷ 99.5 (min.s x 10) oF
11
r.HC
Control output operating mode
H Heating;
C Cooling.
C
P. - Compressor protection and power on delay parameters
Parameter Description Range Default Note
12
P.P1
Output activation delay oF/0.01 ÷ 9.59 (min.s) ÷ 99.5 (min.s x 10) oF
13
P.P2
Delay after output switch OFF oF/0.01 ÷ 9.59 (min.s) ÷ 99.5 (min.s x 10) oF
14
P.P3
Minimum time between two output power ON oF/0.01 ÷ 9.59 (min.s) ÷ 99.5 (min.s x 10) oF
15
P.od
Delay output activation at power ON oF/0.01 ÷ 9.59 (min.s) ÷ 99.5 (min.s x 10) oF
A. - Alarm parameters
Parameter Description Range Default Note
16
A.Ay
Temperature alarms type
1 Absolute to Pr1;
2 Relative to Pr1 .
1
17
A.HA
High Temperature Alarm threshold oF/-99.9 ÷ +999°C/°F oF
18
A.LA
Low Temperature Alarm threshold oF/-99.9 ÷ +999°C/°F oF
19
A.Ad
Temperature Alarms Differential 0 ÷ 30°C/°F 1.0
20
A.At
Temperature Alarms delay oF/0.01 ÷ 9.59 (min.s) ÷ 99.5 (min.s x 10) oF
21
A.PA
Temperature Alarms delay at power on oF/0.01 ÷ 9.59 (h.min) ÷ 99.5 (h.min x 10) 2.00
o. - Buzzer configuration parameters
Parameter Description Range Default Note
22
o.bu
Buzzer function mode
oF Disable;
1 Active alarms only;
2 Key pressed only;
3 Active alarms and key pressed.
3
t. - Keyboard parameters
Parameter Description Range Default Note
23
t.UF
Function mode key
oF No function;
1 ÷ 4 Switch ON/OFF (Stand-by).
oF
24
t.Lo
Keyboard lock function delay OF/0.01 ÷ 9.59 (min.s) ÷ 30.0 (min.s x 10) oF
25
t.PP
Password to access the parameter setting mode oF/999 oF
