Ascon Tecnologic - Y33- Line - Operating Instructions - Pag. 9
11 HOW TO ORDER
Model
Z31A = Instrument with mechanical keys
Z31AS = Instrument with Sensitive Touch
a: Power supply
H = 100... 240 VAC
G = 12... 24 VAC/DC
F = 12 VAC/DC
b: Output (Out)
R = Out Relay SPST-NA 16A-AC1 (resistive load)
S = Out Relay SPDT 16A-AC1 (resistive load)
d: Terminal block
- = Screw terminals (standard)
E = Removable screw terminal block (complete)
N = Removable screw terminal block
(the fixed part only)
e: Display
- = Red
B = Blue
c: Buzzer
- = Not present
B = With Buzzer
cab de fgh
f, g, h: Reserved codes;
ii, jj: Special codes.
ii jj
Note: To order the optional Screw type Bracket necessary
to obtain the IP65 Front protection degree, please,
contact your Ascon Tecnologic supplier
