ascon G2 Series User Manual

17
4 - Operation
ConfConf
O.Ity
H.C.OP
s.Out
rtH
Conf
Il1 Al.1
AI.Ou
ltch
bloc
Al.2
A2.Ou
ltch
Al.3
A3.Ou
ltch
bloc
Al.4
A4.Ou
Il2
bloc
Out L.inP AlM
ltch
C.C.OP
O.r.ty
rt.lo
rt.Hi
éPid:r
éOFF
éOFF
énone
é4=20
é0
é9999
éOFF
éOFF
éOFF
éOFF
éOP1
éno
éno
éOFF
éOP1
éno
éno
éOFF
éOP1
éno
éno
éOFF
éOP1
éno
CONFIGURATION MENU
Output
Configuration
Digital inputs
configuration
Alarm s
configuration
Type of Control
see Table 5
Heat control output
see Table 6
Control output
safety value
Off/ -100…100%
Retransmission output
(available for DC output
only)
none / pU / s.p.
Retransmission output
type
(available for DC output only)
see Table 4
Retransmission
low range
whole range
Retransmission
high range
whole range
Cool control output
see Table 7
AL1 alarm type
see Table 9
AL1 addressing
(not available when AL1 is
OFF)
OpI / Op2/ Op3
AL1 latching
(not available when AL1 is
OFF)
no / yes
AL1 start-up disabling
(not available when AL1 is
OFF)
no / yes
AL2 alarm type
see Table 9
AL2 addressing
(not available when AL2 is
OFF)
OpI / Op2/ Op3
AL2 latching
(not available when AL2 is
OFF)
no / yes
AL2 start-up disabling
(not available when AL2 is
OFF)
no / yes
AL3 alarm type
see Table 9
AL3 addressing
(not available when AL3 is
OFF)
OpI / Op2/ Op3
AL3 latching
(not available when AL3 is
OFF)
no / yes
AL3 start-up disabling
(not available when AL3 is
OFF)
no / yes
AL4 alarm type
see Table 9
AL4 addressing
(not available when AL4 is
OFF)
OpI / Op2/ Op3
AL4 latching
(not available when AL4 is
OFF)
no / yes
AL4 start-up disabling
(not available when AL4 is
OFF)
no / yes
Back to the 1st parameter of Out=Conf
IL1 function
see Table 8
IL2 function
see Table 8
Back to the
1st parameter of
L.inp=Conf
