6 - Technical specification
Features
(at 25°C enviromental temp.)
Operating mode
and Outputs
Control mode
OP1 output
OP2 output
AL1 alarm
(indicator with 2 alarms)
AL2 alarm
Description
1 PID loop or 1 ON-OFF
loop with 1 Alarm
Indicator with 2 alarms
Control output
OP1 - relay or Triac OP2 - SSR drive or relay
AL2 alarm
OP2 - SSR drive or relay OP1 - relay or Triac
AL1 alarm AL2 alarm
OP1 - relay or Triac OP2 - SSR drive or relay
OP2 - SSR drive or relay OP1 - relay or Triac
Algorithm PID with overshoot control or ON OFF
Hysteresis 0.1…10,0% c.s.
Proportional band (P) 0.5…999.9%
Integral time (I) 0.1…100.0 min
OFF = O
Derivative time (D) 0.01…10.00 min
Cycle time 1…200 s
Overshoot control 0.01…1.00
High limit 100.0…10.0%
Hysteresis 0.1…10.0%
SPST relay N.O., 2A/250Vac (4A/120Vac) for resistive load
Triac, 1A/250Vac for resistive load
Hysteresis 0.1…10.0% full scale
Active high
Active low
SSR drive, not isolated: 5Vdc, ± 10%, 30mA max.
SPST relay N.O., 2A/250Vac (4A/120Vac) for resistive load
Absolute threshold: full scale
ON-OFF algorithm
PID algorithm
Action
Active high
Active low
Action type
Deviation threshold ±range
band threshold 0…range
Absolute threshold whole range
Special function Sensor break
