ascon M1 line User Manual

8
2 - Electrical connections
2 ELECTRICAL CONNECTIONS
2.1 TERMINAL BLOCK [1]
B
Pin connector
q 1.4 mm
0.055 in max.
Ø
Fork-shape
AMP 165004
Ø 5.5 mm - 0.21 in
Stripped wire
L 5.5 mm - 0.21 in
Terminals
L
0,5
Nm
6
5
4
3
2
1
12
11
10
9
8
7
16
15
Rear
terminal
cover
Wire size 1 mm
2
(18 AWG Solid/
Stranded) [2]
5.7 mm
0.22 in
14 screw terminals
Option terminals
Tightening torque
0.5 Nm
Pillips screwdriver
PH1
Flat blade screwdriver
0.8 x 4 mm
1
TC
mA
mV
OP1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
b
B
A
RTD
L
N
NO
C
RS485
(OP4)
OP2 - L
18V—
OUT
N/C
N/C
N/C
N/C
NO
C
F50-
474 1A1M1
OP2 - R
UL notes
[1] Use 60/70 °C copper (Cu)
conductor only.
[2] Wire size 1mm
2
(18 AWG
Solid/Stranded)
M1UK.ed5 14-05-2009 14:56 Pagina 8
