OPERATING MANUAL
7610-4700-1201
Issue A
3-2
Accessory:
External Accessory: This menu option is selected when an external accessory is attached
to the radio, which cannot be found by the radio automatically. Thus radio turns it
loudspeaker off.
Password:
This menu is take place at the radios, which do not have crypto. If password query is
turned on from Password/Password Query sub menu, radio asks password to the user at
the first opening. Existing password can be changed from Password/Password Change.
Serial Port:
Option connector can be connected to different terminals with different rates and serves
different services. For each process connector is taken to appropriate values by this menu.
Data: This menu option is selected for programming of the radio with programming
(AP25TP47) or adjustment (A4700) software or making data communication through radio.
If "data" is not selected software cannot connect with the radio.
GPS: This menu option is selected if GPS receiver is connected to the handheld radio.
Squelch:
Radio's receiver can deafen to prevent random turning on of the squelch at the
electromagnetically polluted environment at analog mode. This process can be done from
squelch sub menu as 4 leveled.
Greeting Message:
10 characters greeting message is entered by this menu. When the radio is turned on,
logo and then greeting message appears.
Figure 3-1: ASELSAN Logo
Factory Settings:
To turn back to the factory settings with the help of this option, new values are appointed
to the following parts:
Keypad Tone = 4
Alert Tone, call alert = 4
Illumination = Front – LED: Auto
LCD Contrast = 2
Serial Port = Data
Squelch = 0
Greeting Message = ASELSAN
Channel list = All conventional channels are included by scanning list, no priority channel
Group scan = On
