5-1
5 HOW TO USE
• Be sure that antenna and battery block is connected truly before turning on the radio.
• Turn on the radio by turning the On/Off-Volume Switch in the clockwise direction.
• Enter the attached CIK unit's PIN code.
• Adjust the volume to required level by using On/Off-Volume Switch.
• Channel switch is turned to the required channel. Radio is waited to be registered to
the channel through system.
• To make transmission PTT Button is pressed and it is hold pressed during
transmission. LED at the top of the radio lights red during transmission.
• Output power of the radio can be selected as Low, Medium or High by pressing
Mode and Power Change Button.
• When transmission has finished PTT Button is released to pass receiving position.
LED at the top of the radio lights blue during receiving.
• Radio is turned off by turning On/Off-Volume Switch in the counter-clockwise
direction.
5.1 REMOVING AND ATTACHING OF THE BATTERY BLOCK
WARNINGS
Do not EVER throw batteries to fire.
At misusages batteries may release damaging chemical gasses. In
this case;
DO NOT BREATHE THE SMOKE,
LEAVE THAT PLACE AS SOON AS POSSIBLE
VENTILATE THE PLACE
Misusage of batteries may cause fire and/or explosion.
Do not try to open battery block. Battery cells contain electrolyte
liquids, which may be damaging for skin and clothes. Do not touch to
the crack battery cells with naked hand.
