12 Parts list
12.1 Replacement diaphragms
Material
0.5"
Standard
0.5"
Extended
1.0" 1.5" 1.5/2.0" 3" 4"
Silicone SL05 SG05 SL10 SL17 SL20 SL30 SL40
Silicone Plus PS05 PSG05 PS10 PS17 PS20 PS30 N/A
EPDM EP05 EG05 EP10 EP17 EP20 EP30 EP40
EPDM Plus PE05 PEG05 PE10 PE17 PE20 PE30 N/A
Viton A VT05 VG05 VT10 N/A VT20 VT30 N/A
Viton A
(steam grade)
VA05 N/A VA10 N/A VA20 VA30 N/A
Viton GF N/A VGF05 N/A N/A VF20 VF30 N/A
PTFE N/A PFG05-1 PF10-1 PF17-1 PF20-1 PF30-1 N/A
12.2 Actuator maintenance kits
MNXX/PNXX Series (Stainless steel actuators)
Part # Applicable To Description
MAK-100 0.5" - 3.0" manual actuators
Includes O-rings, guide bushing, and wiper
seal
MAK-400 4.0" manual actuator
Includes O-rings, guide bushing, and wiper
seal
PAK-050 0.5” pneumatic actuator
Includes O-rings, guide bushing, and quad
ring
PAK-100 1.0” pneumatic actuator
Includes O-rings, guide bushing, and quad
ring
PAK-200 1.5”/2.0” pneumatic actuator
Includes O-rings, guide bushing, and quad
ring
PAK-300 3.0" pneumatic actuator
Includes O-rings, guide bushing, and quad
ring
PAK-400 4.0" pneumatic actuator
Includes O-rings, guide bushing, and quad
ring
m-radialdiaphragmvalve-en-02 37
