V2000 – Installation Guide
Copyright © 2015 Application Solutions (Safety and Security) Limited
Application Solutions (Safety and Security) Limited
Unit 17 Cliffe Industrial Estate
Lewes - East Sussex
BN8 6JL - UK
Tel: +44(0)1273 405411 Fax: +44(0)1273 405415
All rights reserved.
Information contained in this document is believed to be accurate, however no representation or warranty is given and Application
Solutions (Safety and Security) Limited assumes no liability with respect to the accuracy of such information.
U-0623-0291.docx – Issue: 04 complete, approved
Page 2 of 40
This equipment is designed and manufactured to conform to the following EC standards:
EMC: EN 55103-1/E1, EN 55103-2/E5, EN 50130-4, EN 50121-4, EN 61000-6-2 and EN 61000-6-3
Safety: EN 60950-1 (Class I, Over-voltage category 2, pollution degree 2)
Professional equipment (not intended for sale to the general public) with rated power greater than 1 kW.
A ‘Declaration of Conformity’ statement to the above standards is available on request.
Failure to use the equipment in the manner described in the product literature will invalidate the warranty.
This product must be disposed of in accordance with the WEEE directive.
Contents
1 Introduction ................................................................................................................................................................. 3
2 Safety and Precautions ............................................................................................................................................... 4
3 Preparation ................................................................................................................................................................. 7
4 Unpacking and Handling ............................................................................................................................................. 8
5 Installation................................................................................................................................................................... 9
6 Connections .............................................................................................................................................................. 26
7 Technical Specification ............................................................................................................................................. 31
8 Mechanical Dimensions ............................................................................................................................................ 34
9 Storage and Preservation ......................................................................................................................................... 35
10 Packing for Return .................................................................................................................................................... 36
Additional User Documentation:
1) V2000 User’s Manual (ASL U-0623-0383)
2) ASL System Design Guide (ASL T-0667-0185)
3) Additional reference information is available from the ASL’s website: www.asl-control.co.uk
