V2000 – Installation Guide
U-0623-0291.docx – Issue: 04 complete, approved
Page 3 of 40
1 Introduction
This document describes how to install the V2000 Amplifier Mainframe and associated Interface Cards into a
pre-wired equipment rack.
The diagram below provides an overview of the installation sequence.
Summary of Task Section Step(s) Page
Safety and Precautions Read the safety and precautions instructions and guidelines. 2 All 4
Preparation Gather documentation, tools, equipment and rack. 3 All 7
Unpacking and Handling Unpack equipment. 4 All 8
Installation 1. Place the required equipment close to the rack. 5 1 9
2. Remove the front panel. 2 10
3. Remove the lid. 3 10
4. Check the DIP switch settings. 4 11
5. Set the Earth Lift Switch. 5 11
6. Remove the LSZDC Surveillance Blanking Plates. 6 11
7. Install V2000-STBY Interface Cards (if used). 7 12
8. Cover unused standby interface card slots with blanking plate. 8 13
9. Set standby links. 9 14
10. Cover unused surveillance interface card slots with blanking plate. 10 16
11. Install LSZDC Interface Cards. 11 17
12. Re-fit the lid. 12 18
13. Check rotary switch settings. 13 19
14. Isolate power supplies. 14 19
15. Install mainframe into the rack. 15 20
16. Switch the mainframe MAINS and POWER switched off. 16 20
17. Fit Amplifier Modules. 17 21
18. Connect field wiring to interface cards and control ports. 18 23
19. Connect auxiliary DC power supply cable. 19 23
20. Connect AC mains supply cable. 20 24
21. Connect battery supply cable. 21 24
22. Connect thermistor cable. 22 25
23. Commission V2000 mainframe. 23 25
No commissioning instructions are provided in this document.
Refer to V2000 User’s Manual (ASL U-0623-0383).
24. Fit the front panel. 24 25
