V2000 – Installation Guide
U-0623-0291.docx – Issue: 04 complete, approved
Page 7 of 40
3 Preparation
Read and observe the safety instructions and guidelines in Section ‘2 Safety and Precautions’
Failure to follow these instructions and guidelines may cause personal injury and/or damage to
the
equipment.
Gather the following documentation and tools:
• The system design documentation of the specific location
• A small flat-bladed screwdriver
• Pozidriv screwdrivers (No 1, 2 and 3)
• A pair of wire cutters/strippers
• 19-inch rack-mount fixing screws as required by the system design
• Ferrules and crimping tool
• ESD wrist strap or other grounding device
• Antistatic mat or antistatic foam
Gather the equipment (in their original packing):
• The V2000 Amplifier Mainframe
• D500 and/or D150 amplifier module(s) as required by the system design
• Interface cards as required by the system design: LSZDC V2000 Line Surveillance Interface
Card and V2000-STBY V2000 Standby Interface Card
• Surveillance blanking plates as required by the system design
• Thermistor cable assembly as required by the system design (if not part of the rack build)
A standard 19-inch rack is required for the installation.
The rack should be fitted with battery backup system (if used), supporting rails for the V2000
mainframe, fan trays (if required), cooling ducts (if required), ventilation panels (if required) and wired
with power supply, signal, and control wiring to suit the requirements of the specific system design
should meet the rules and guidelines provided in the ASL System Design Guide
(ASL T-0667-0185).
Note that the installation of fan trays, cooling ducts, and/or ventilation panels depend on the system
design; refer to the ASL System Design Guide for further details.
