Page #48 background imageLoading...
Page #48 background image
VAR8 and Variants - Product Description
Issue: 02 complete, approved
Page 48 of 54
Audio General
THD Input to Output .............................................................................................................. <0.1 % @1 kHz
Crosstalk................................................................................................................................ >70 dB @1 kHz
Residual Noise ............................................................................................................................ <78 dBu (A)
S/N Line......................................................................................................................................... >70 dB (A)
Frequency Response (Input to Output) ................................................................... 100 Hz to 20 kHz, –3 dB
Audio Monitoring
SPL from Loudspeaker (Sounder Mode)...................... 50 dBA @ 1 m from the equipment enclosure
Frequency Response (From Input through to Speaker)................................... 200 Hz to 10 kHz 3 dB
Gain Range Control (Front panel rotary encoder) ................................................................ 0 to –63 dB
Audio Routing
Number of Concurrent Host Routes ................................................................................................ 20 (max.)
Override per Output......................................................................................................................... 40 (max.)
Control Ports
Digital Inputs
4
Number of Digital Inputs.............................................................................................................. 10 on VAR8
20 on VAR8-E
Interface.................................................. Opto-isolated with built-in resistor to suit voltages of +12 to +40 V
Analogue Inputs (on VAR8 with EFI01)
4
Number of Analogue Inputs...........................................................................................................................8
Interface........................................ Non-isolated analogue interfaces with internal pull-up to +5 V by 4.7 k
Maximum External Fault Active-Low Input Voltage Threshold............................................................... 2.5 V
Monitored Analogue Contact Thresholds .......................................... Faulty – Open Circuit: .............. >3.7 V
Healthy – Inactive: .........2.5 V – 3.7 V
Indeterminate: ................0.8 V – 2.5 V
Healthy – Active: ............0.2 V – 0.8 V
Faulty – Short Circuit: .............. <0.2 V
Digital Outputs (on VAR8 with EFI01)
4
Number of Digital Outputs .............................................................................................................................8
Interface................................................................................................................................... Open-collector
Others
Open Collector Drive (SPEAK NOW LED, ALL CALL LED) .............................................................. 100 mA
Changeover Fault Relay................................................................................................................................1
Maximum Global Fault Relay Contact Current Rating: 500 mA
RS485 Port ....................................................................................................................................................1
Up to 6 Units: Remote I/O Units (BMB01) and/or Fire Loop Interfaces
RS232 Port ....................................................................................................................................................1
For mutually exclusive use by Host PC for configuration, Intellevac Network
5
,
or PC/DVA system
6
4
When the VAR8 is fitted with an EFI01, the 10 digital inputs on the VAR8 base unit are replaced by the EFI01 analogue inputs and
digital outputs.
5
The RS232 port is internally used for system networking when the VAR8 is fitted with the ANIC Network Interface Card. It may be
temporarily disconnected from the network, and connected to a Host PC for configuration purposes.
6
PC/DVA system can only be connected to stand-alone VAR8.
