4. PRODUCT DESCRIPTION
ASPIRE EVOKE 2 MANUAL WHEELCHAIR
The Aspire Evoke 2 Manual Wheelchair is a lightweight four wheel wheelchair with a cross folding frame.
The product is made of aircraft grade aluminium, ensuring strength, durability and easy movement. This
wheelchair offers enhanced manoeuvrability and stability, a wide size range and leading adjustability for
a customised fit. It is equipped with a fabric seat and back, seat cushion, push handles, large 24 inch rear
self-propelling quick release wheels and removable swing away legrests. A large range of accessories
can be fitted to the Aspire Evoke 2 Manual Wheelchair to improve its overall performance.
ASPIRE EVOKE 2 JNR MANUAL WHEELCHAIR
The Aspire Evoke 2 JNR Manual Wheelchair is a lightweight four wheel wheelchair with a cross folding
frame. The product is made of aluminium, ensuring strength durability and easy movement. This
wheelchair offers enhanced manoeuvrability and stability, a wide size range and leading adjustability
for a customised fit. It is equipped with a fabric seat and back, seat cushion, push handles, medium
20 inch rear self-propelling quick release wheels and removable swing away legrests. A large
range of accessories can be fitted to the Aspire Evoke 2 JNR Manual Wheelchair to improve its
overall performance.
5. WARNINGS
MAXIMUM WEIGHT CAPACITY – 150kg / 23.6st – 350 – 500mm / 13.7" – 19.6" SEAT WIDTHS
MAXIMUM WEIGHT CAPACITY – 190kg / 29.9st – 570 – 610mm / 22.4" – 24" SEAT WIDTHS
DO NOT exceed maximum user weight. This weight limit includes any accessories, shopping
or other personal items that may be carried on the chair. The maximum weight capacity is
defined with respect to a typical body shape, where body mass is evenly distributed. Users
with dysmorphic body shapes or amputees should be assessed by an accredited healthcare
professional prior to choosing/using this wheelchair.
DO NOT stand on the foot plates as the wheelchair may tip forwards. The foot plates are not
designed to be a weight bearing surface.
DO NOT use the wheelchair on escalators, even if accompanied by an attendant.
DO NOT use the wheelchair on escalators, even if accompanied by an attendant.
ALWAYS use push rims to bring the wheelchair to a stop. DO NOT use the brakes to stop
a moving wheelchair.
WARNING
WARNING! Pay attention to your fingers when folding or opening the wheelchair and when
self-propelling the chair with hands in close proximity to wheel spokes.
ASPIRE EVOKE 2 MANUAL WHEELCHAIR
CODE
SEAT
WIDTH
(mm / inches)
OVERALL
WIDTH
(mm / inches)
SEAT
DEPTH
(mm / inches)
SEAT
HEIGHT
(mm / inches)
BACKREST
HEIGHT
(mm / inches)
ARMREST
HEIGHT
(mm / inches)
MINIMUM
CHAIR
WEIGHT
(kg / lb)
SWL
(kg / st)
EVOKE 2
MWS449500
350 560 300 – 450 450 – 500 430 – 490 210 – 230 14.8 kg 150 kg
14" 22" 11.8" – 17.7" 17.1" – 19.6" 16.9" – 19.2" 8.26" – 9" 32.6lbs 23.6st
MWS449510
400 610 300 – 450 450 – 500 430 – 490 210 – 230 14.9 kg 150kg
16" 24" 11.8" – 17.7" 17.1” – 19.6” 16.9” – 19.2” 8.26" – 9" 32.8lbs 23.6st
MWS449520
450 660 300 – 450 450 – 500 430 – 490 210 – 230 15.0 kg 150 kg
18" 25.9" 11.8" – 17.7” 17.1” – 19.6” 16.9” – 19.2” 8.26” – 9” 33lbs 23.6st
MWS449530
500 710 400 – 550 450 – 500 430 – 490 210 – 230 15.1 kg 150 kg
20" 27.9" 15.7" – 21.6" 17.1” – 19.6” 16.9” – 19.2” 8.26” – 9” 33.2lbs 23.6st
MWS449540
HD
570 780 400 – 550 450 – 500 430 – 490 210 – 230 16.0 kg 190 kg
22" 30.7" 15.7" – 21.6” 17.1” – 19.6” 16.9” – 19.2” 8.26” – 9” 35.2lbs 29.9st
MWS449550
HD
610 820 400 – 550 450 – 500 430 – 490 210 – 230 16.2 kg 190 kg
24" 32.2" 15.7" – 21.6” 17.1” – 19.6” 16.9” – 19.2” 8.26” – 9” 35.7lbs 29.9st
ASPIRE EVOKE 2 JNR MANUAL WHEELCHAIR
CODE
SEAT
WIDTH
(mm / inches)
OVERALL
WIDTH
(mm / inches)
SEAT
DEPTH
(mm / inches)
SEAT
HEIGHT
(mm / inches)
BACKREST
HEIGHT
(mm / inches)
ARMREST
HEIGHT
(mm / inches)
MINIMUM
CHAIR
WEIGHT
(kg / lb)
SWL
(kg / st)
EVOKE 2 JNR
MWS449560
300 mm 510 300 – 450 410 – 450 430 – 490 210 – 230 14 kg 150 kg
12” 20" 11.8" – 17.7" 16.1" – 17.7" 16.9" – 19.2" 8.2" – 9" 30.8lbs 23.6st
6. PRODUCT SPECIFICATIONS
