High End Integrated Amplifier ASR Emitter Page 13
Monitor-switch (= below the input selcetor knob)
As an option, the ASR Emitter can be equipped with a tape monitor switch. When the ASR
Emitter is turned on, pressing the tape monitor switch allows you to listen to the source,
that you are recording to the tape unit connected to the „Ta“-input. If the ASR Emitter is in
the „Standby“-mode, pressing the tape-monitor switch activates the adjustments for the
input level adjust, energy saving mode, balnace and display brightness (refer chapter no.
3.4).
3.3 Operating the ASR Emitter via remote control
All functions of the ASR Emitter can be controlled via remote control. To operate the ASR
Emitter via remote control, put the left knob to the „Standby“-position. If you press a key on
the remote control, the display lights up and shows the selected function. When using the
remote control, the three control knobs on the frontpanel of the ASR Emitter are not
moving.
A Philips remote control is supplied with every ASR Emitter. This remote control can learn
codes from up to five other components and control these units. Please read the
instruction manual of the Philips remote control carefully.
Functions of the remote control buttons
Button Function
TV-VCR-SAT-CD-
Audio 1-Audio 2
(grey)
selects the unit, that you want to control via remote control,
(all functions for operation of the ASR Emitter are saved under
„Audio 1“), press the grey button as long until the green LED
above the name of the unit, that you want to control,lights up
I/O
(red, at the top, right)
ASR Emitter on/off
1 – 6 for direct input selection:
1 = „Ph“, 2 = „Ta“, 3 = „CD“, 4 = „Tu“, 5 = „DT“, 6 = „Vi“
7 switches the tape monitor input
equivalent to pressing the tape monitor button (optional) on
the frontpanel of the ASR Emitter
8 resets the ASR Emitter to factory settings (volume will be set
to „40“)
9 and 0 switches the output(s) of the ASR Emitter,
equivalent to turning the left knob one position incl. on/off
Mute lowers the volume (- 15dB), pressing the button again
increases the volume again (+ 15dB)
Vol + increases the volume
the display lights up and indicates the increase
Vol - lowers the volume
the display lights up and indicates the decline
Prog + switches the inputs clockwise
LED above the input selector knob indicates the chosen input
Prog - switches the inputs anticlockwise
LED above the input selector knob indicates the chosen input
