ASR Audiosystems Friedrich Schaefer, D-35727 Herborn, Germany
High End Integrated Amplifier ASR Emitter Page 6
2.1.3 Connecting a tape deck to the ASR Emitter
The ASR Emitter I is equipped with one, the ASR Emitter II with two tape outputs
(additional tape output on special order).
Connect the „Line out“ or „Tape Ot“-RCA sockets on your tape deck to the RCA input
sockets „Ta“ on the ASR Emitter and the „Line In“- or „Tape In“-RCA sockets on your tape
deck to the „Out“-RCA sockets (sockets closest to the heatsinks) on the ASR Emitter.
Additional tape decks or open-reel decks can be connected to each RCA input of the ASR
Emitter. To make recordings, put the input selector knob to the position, where the source
that you want to record from, is connected. The signal of the chosen source component
will be routed to the „Out“-RCA sockets. Tape-to-tape recordings are possible in the same
manner too.
ATTENTION: during a recording or when your tape deck is ready to record, DO NOT
switch the input selector knob to the input, where your (recording) tape deck is connected
to. Switiching to the „Ta“-input means switching tape in- and output together – a feedback
will be the result. This feedback may cause damages to your connected speakers.
2.1.3 Connecting an auxiliary source component to the
ASR Emitter
The „Ta“ input of the ASR Emitter may as well be used to connect any auxiliary source
components like equalizer. Connect the „Line out“-RCA sockets on your auxiliary
component to the RCA input sockets „Ta“ on the ASR Emitter and the „Line In“-RCA
sockets on your auxiliary component to the „Out“-RCA sockets (sockets closest to the
heatsinks) on the ASR Emitter. Pressing the „monitor“-button on the ASR Emitters
frontpanel or on the remote control will bring the signals of the auxiliary component into the
signalpath of the chosen input on the ASR Emitter.
2.1.5 Connecting a pair of speakers to the ASR Emitter
ATTENTION:
Put the left control knob to the „0“ (Off) position before you connect or disconnect any
speakercables. check all speakercabels for shortcuts. This will keep your speakers and the
other connected components from being damaged. A shortcut is easily detectable and is
not covered by the ASR warranty!
The standard versions of the ASR Emitter are equipped with a direct (speaker) output. To
increase the performance of the ASR Emitter, the speaker outputs are directly connected
to the output transistors and named „Direkt“.
An ASR Emitter with direct output differs from an ASR Emitter with a relais-switched
speaker output (read 2.2.5):
- while switching the ASR Emitter on or off, there might be a audible sound in your
speakers
- before switching the ASR Emitter to the „On“-position, the DC resistor can not check, if
a shortcut has occured on the speakers – this means: all speakercables HAVE TO BE
