ASROCK B75M-GL R2.0 User Manual

3
Contents
1 Introduction ........................................................ 5
1.1 Package Contents ......................................................... 5
1.2 Specications ................................................................. 6
1.3 Motherboard Layout ....................................................... 13
1.4 I/O Panel ........................................................................ 14
2 Installation .......................................................... 15
2.1 Screw Holes ................................................................... 15
2.2 Pre-installation Precautions ........................................... 15
2.3 CPU Installation ............................................................. 16
2.4 Installation of Heatsink and CPU fan ............................. 18
2.5 Installation of Memory Modules (DIMM) ........................ 19
2.6 Expansion Slots
(PCI and PCI Express Slots)
.................... 20
2.7 CrossFireX
TM
and Quad CrossFireX
TM
Operation Guide 21
2.8 Dual Monitor and Surround Display Features ................ 25
2.9 ASRock Smart Remote Installation Guide ..................... 29
2.10 Jumpers Setup ............................................................... 30
2.11 Onboard Headers and Connectors ................................ 31
2.12 Serial ATA (SATA) / Serial ATA2 (SATA2) / Serial ATA3
(SATA3) Hard Disks Installation ..................................... 36
2.13 Hot Plug for SATA / SATA2 / SATA3 HDDs .................... 37
2.14 SATA / SATA2 / SATA3 HDD Hot Plug Feature and
Operation Guide ............................................................ 38
2.15 Driver Installation Guide ................................................ 40
2.16 Installing Windows
®
7 / 7 64-bit / Vista
TM
/ Vista
TM
64-bit
/ XP / XP 64-bit Without RAID Functions ................... 40
2.16.1 Installing Windows
®
XP / XP 64-bit Without RAID
Functions............................................................ 40
2.16.2 Installing Windows
®
7 / 7 64-bit / Vista
TM
/
Vista
TM
64-bit Without RAID Functions ............... 41

ASROCK B75M-GL R2.0 Specifications

General

Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	16 GB
Supported memory clock speeds	1066, 1333, 1600 MHz
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Core i3, Intel Core i5, Intel Core i7
CPU fan connector	Yes
USB 2.0 connectors	-
Number of SATA II connectors	5
S/PDIF in connector	No
Internal memory type	DDR3
eSATA/USB 2.0 ports quantity	0
USB 2.0 ports quantity	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
Certification	FCC, CE, WHQL ErP/EuP Ready
Component for	PC
Power source type	ATX
Motherboard chipset	Intel B75
Audio output channels	5.1 channels
Motherboard form factor	micro ATX
Compatible operating systems	Windows 7 / 7 64-bit / Vista / Vista 64-bit / XP / XP 64-bit
Supported storage drive interfaces	SATA III
Maximum resolution	2048 x 1536 pixels
PCI Express slots version	2.0, 3.0
LAN controller	Realtek RTL8111E
Networking features	LAN
Ethernet interface type	Gigabit Ethernet
BIOS type	AMI
ACPI version	1.1
BIOS memory size	64 Mbit

Weight and Dimensions

Depth	213 mm
Width	244 mm
