ASROCK B75M-GL R2.0 User Manual

36
2.12 Serial ATA (SATA) / Serial ATA2 (SATA2) / Serial ATA3 (SATA3)
Hard Disks Installation
This motherboard adopts Intel
®
B75 chipset that supports Serial ATA (SATA) / Serial
ATA2 (SATA2) / Serial ATA3 (SATA3) hard disks. You may install SATA / SATA2 /
SATA3 hard disks on this motherboard for internal storage devices. This section will
guide you to install the SATA / SATA2 / SATA3 hard disks.
STEP 1: Install the SATA / SATA2 / SATA3 hard disks into the drive bays of your
chassis.
STEP 2: Connect the SATA power cable to the SATA / SATA2 / SATA3 hard disk.
STEP 3: Connect one end of the SATA data cable to the motherboard’s SATA2 /
SATA3 connector.
STEP 4: Connect the other end of the SATA data cable to the SATA / SATA2 /
SATA3 hard disk.

ASROCK B75M-GL R2.0 Specifications

General

Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	16 GB
Supported memory clock speeds	1066, 1333, 1600 MHz
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Core i3, Intel Core i5, Intel Core i7
CPU fan connector	Yes
USB 2.0 connectors	-
Number of SATA II connectors	5
S/PDIF in connector	No
Internal memory type	DDR3
eSATA/USB 2.0 ports quantity	0
USB 2.0 ports quantity	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
Certification	FCC, CE, WHQL ErP/EuP Ready
Component for	PC
Power source type	ATX
Motherboard chipset	Intel B75
Audio output channels	5.1 channels
Motherboard form factor	micro ATX
Compatible operating systems	Windows 7 / 7 64-bit / Vista / Vista 64-bit / XP / XP 64-bit
Supported storage drive interfaces	SATA III
Maximum resolution	2048 x 1536 pixels
PCI Express slots version	2.0, 3.0
LAN controller	Realtek RTL8111E
Networking features	LAN
Ethernet interface type	Gigabit Ethernet
BIOS type	AMI
ACPI version	1.1
BIOS memory size	64 Mbit

Weight and Dimensions

Depth	213 mm
Width	244 mm
