1.7 Block Diagram
AMD Family 19h 10h-1Fh Processor
CPU
GENOA SP5
Socket SP5 (SMLGA-6096)
Support Max：400 W
1DPC support 8 DIMM with RDIMM/LRDIMM
CHG CHH
CHI
CHK
CHA
CHB CHC
CHE
1 x DDR 5 RDIMM/LRDIMM 1 x DDR5 RDIMM/LRDIMM 1 x DDR 5 RDIMM/LRDIMM 1 x DDR 5 RDIMM/LRDIMM
1 x DDR 5 RDIMM/LRDIMM 1 x DDR 5 RDIMM/LRDIMM 1 x DDR 5 RDIMM/LRDIMM 1 x DDR 5 RDIMM/LRDIMM
PCIe Gen5 x16
P2
PCIE2
PCIe Gen5 x16
PCIe Gen5 x16
P1
PCIE6
PCIe Gen5 x16
PCIe Gen5 x16
P0
PCIe Gen5 x16
G0
PCIe Gen5 x16
G1
PCIE5
PCIE3
PCIe Gen3 x4
P4
BCM57416 : 10GbE x2
RJ45 : LAN2
PCIe Gen3 x4
NCSI
PCIe Gen5 x16
PCIe Gen5 x8
RJ45 : LAN1
PCIe Gen5 x16
P3
PCIe Gen5 x8
G2
Phison PS7101
PCIe Gen5 x8
M2_2 x4
MCIO4 x4
PCIE1 : PCIe Gen5 x16/x8
x4
x4
PCIe Gen5 x8
SATA3 x8
G3
Phison PS7101
PCIe Gen5 x8
SATA3.0 x8
MCIO1 x4
PCIE7 : PCIe Gen5 x8x8
x4 (default)
PCIe Gen5 x4
SATA3 x4
G3
M2_1
PCIe Gen5 x4
SATA3.0 x4
MCIO2 x4
PCIe Gen5 x4
SATA3 x4
G3
MCIO3
PCIe Gen5 x4
SATA3.0 x4
PCIE4 PCIe Gen5 x16
PCIe Gen5 x8
G2
PCIe Gen5 x8
x8 (default)
PCIe Gen3 x1
P5
BMC AST2600
PCIe Gen2 x1
USB10_DP
USB2.0
ESPI
ESPI
SIO
NCT6796D-S
SPI
TPM (SP I)
DDR4 DRAM
(512MB)
SPI FLASH
(64MB)
RTL8211F RJ45
IPMI
VGA
VGA_COM
USB3_3_4
(Front)
USB3_1_2
(Rear)
USB3.2
Gen1
USB3.2 Gen1 x2
USB3.2 Gen1 x2
Single BIOS ROM
(32MB)
6 Pin-FAN*8
SGPIO
SGPIO Header x2
Speaker
USB11_DP
USB3_HUB
USB2.0 x2
80-LED
PCIe Gen5 x16PCIE0
COM2
On board
VGA
Optional
Phison PS7101
PCIe Gen5 x8
Phison PS7101
PCIe Gen5 x8
x4 (Jump er opt ion)
PCIe Gen5 x8
