GENOAD8X-2T/BCM
2 3
English
USB
Controller/Hub AMD EPYC 9004
Connectors/Headers External:
2 Type-A (USB3.2 Gen1)
Internal:
1 header (19-pin, 2 USB3.2 Gen1)
Graphics
Controller ASPEED AST2600: 1 DB15 (VGA)
Security
TPM 1 (13-pin, SPI)
Rear I/O
UID Button/LED 1 UID button w/ LED
VGA Port 1 DB15 (VGA)
Serial Port 1 DB9 (COM)
USB 2 Type-A (USB3.2 Gen1)
RJ45 2 RJ45 (10GbE), 1 dedicated IPMI
Hardware Monitor
Temperature CPU, MB, TR1 Temperature sensing
Fan CPU/Rear/Front Fan Tachometer
CPU Quiet Fan (Allow Chassis Fan Speed Auto-Adjust by
CPU Temperature)
CPU/Rear/Front Fan Multi-Speed Control
Voltage VCORE,VCCSA,VCCM,3V, 5V, 12V, +1.05V_PCH_
AUX,+BAT, 3VSB, 5VSB,VCCIO,+2.5V_VPP
Server Management
BMC Controller ASPEED AST2600: IPMI2.0 with iKVM and vMedia support
IPMI Dedicated
GLAN
1 Realtek RTL8211F for dedicated management GLAN
System BIOS
Type AMI UEFI BIOS; 256 Mb (32MB) SPI Flash ROM
Features ASRock Rack Instant Flash, ACPI 6.4 and abouve compliance
wake up events, SMBIOS 3.5.0 and above, Plug and Play(PnP)
Other Internal Connectors/Headers
PSU Connector 1 (24-pin, ATX main power), 3 (8-pin, ATX 12V)
Auxiliary Panel
Header
1 (18-pin): chassis intrusion, system fault LED, LAN1/LAN2
activity LED, locate, SMBus
System Panel Header 1 (9-pin): power switch, reset switch, system power LED,
HDD activity LED
NMI Header 1
COM Header 1
VGA Header 1
Speaker Header 1 (4-pin)
Fan Header 8 (6-pin)
ermal Sensor
Header
1
