I have a retro-fit with LEDs (power is being
sent on old green wire to continuously power
LEDs), will I have to re-wire the installation:
The lock is retro-fittable to the old lock and a 9 – 12 pin adaptor
(SP3782EL-251) is available.
• The 9 – 12 pin adaptor will operate the lock in 2 wire mode
and thus the LEDs however in PTO mode, the LED’s will
operate for a few seconds only.
• 2 wire PtO is not recommended
I am trying to set the LEDs on site, how can I
power the lock:
The lock can be powered via a micro-USB connector connected to
a power bank, PC or mobile phone charger or it can be powered by
the main connector with a 9 or 12V battery connected to the red
(+) and black (-) wires
Refer to instructions for LED activation steps
I am trying to lock one side of the lock but the
cabling has not been installed – how can I do
this:
Set setting switches to required position (PtO will leave the lock
locked once power has been removed)
The lock can be powered via a micro-USB connector connected to
a power bank, PC or mobile phone charger or it can be powered by
the main connector with a 9 or 12V battery connected to the red
(+) and black (-) wires
• If powering by USB, the setting will only take effect after
30 seconds or if immediate response is required – while
powered, briefly press the LED and mode button and the
lock will change to and remain in the failed state. When
the lock is powered through the main connector, normal
operation will resume
• If powering through the main connector, connect and
remove the green wire from the positive terminal of the
battery
• Ensure power is supplied to the lock for at least 5 seconds
