11
P/N - - - Rev BYRL EMICL PBINSTL FUL
5
Adjusting Deadbolt Latch
(If adjustable deadbolt latch provided)
O
optional
default
UP
2-3/8" position
UP
2-3/4" position
Press
Pull
