15
P/N - - - Rev BYRL EMICL PBINSTL FUL
9
Securing Back Plate to Door
x2
!
!
Two #6-32 x 1/2"
POHMS screws must
be used to qualify for
listing.UL
Drill two
pilot holes
Ø1/8"
x 1/2" deep
Inside of Door
U
P
#6-32 x 1/2" POHMS
