18
P/N - - - Rev BYRL EMICL PBINSTL FUL
11
Installing Interior Lock
Turn
thumbturn
to adjust slot
orientation.
!
!
U
P
Orientation must match.
Do not fasten lock to back plate
until properly fitted.
Inside of Door
