19
P/N - - - Rev BYRL EMICL PBINSTL FUL
11
Installing Interior Lock continued
10-32 x 5/8" POHMS
x1
6-32 x 1" PPHMS
x2
Inside of Door
DO NOT
LOOSEN
THIS SCREW
!
