Assa Abloy Yale YRD216-ZW3 User Manual

26
Battery is fully charged
0x80
0x05
After a low battery alert was observed,
the lock was powered down and
powered back up with full battery.
0x08
0x0D
Handing Cycle
completed
0x81
0x00
Right-handed install
0x06
0xFE
0x01
Left-handed install
0x06
0xFE
Door Lock needs Time
set / RF Module Power
Cycled
0x82
0x00
Power to the lock was restored and the
locks RTC was cleared. The controller
should set the time to ensure proper
logging.
0x08
0x01
Disabled user entered
at keypad
0x83
0x (01-
max
users)
A disabled user pin code was entered at
the keypad
0x06
0xFE
Valid user but outside
of schedule
0x84
0x (01-
max
users)
A valid user can be both a normal user
and a non-Access user. If a non-access
user is out of schedule this alarm will be
sent instead of the non-access alarm.
0x06
0xFE
Tamper Alarm
0xA1
0x01
keypad attempts exceed code entry limit
0x06
0X10
0x02
front escutcheon removed from main
0x06
0xFE
Low Battery Alarms ³
0xA7
0x
(Current
%)
Low Battery
Starting at 4.0V [0x8002 & 0x8004];
4.6V [0x8109, 0x810A, 0x8103, 0x8104
& 0x8113]
0x08
0x0A
0xA8
0x
(Current
%)
Critical Battery Level Starting at 3.9V
[0x8002 & 0x8004]; 4.4V [0x8109,
0x810A, 0x8103, 0x8104 & 0x8113]
0x08
0x0B
Integrated BLE Lock ⁴
0xE2
0x00
Integrated BLE Lock
0x06
0x03
0x01
Integrated BLE Auto Relock
0x06
0x09
Integrated BLE Unlock
⁴
0xE3
0x00
Integrated BLE Unlock
0x06
0X04
0x01
Integrated BLE Auto Unlock
0x06
0X04
Homekit BLE Lock ⁴
0xE4
0x00
Integrated Homekit BLE Lock
0x06
0x03
Homekit BLE Unlock ⁴
0xE5
0x00
Integrated Homekit BLE Unlock
0x06
0X04
¹ Deleting all user codes will also delete any associated schedules (year day and daily repeating scheduled pin codes) assigned to user codes.
² Only supported by YRD410/420/430/450. This requires additional Hardware and calibration within the Yale Access App.

Assa Abloy Yale YRD216-ZW3 Specifications
