4.2. TECHNICAL CHARACTERISTICS
Main technical data of the machines of the series:
• OPTIMA:
TABLE 1: TECHNICAL DATA [OPTIMA CHILLER], pág. 46.
• MAYA:
TABLE 2: TECHNICAL DATA [MAYA REVERSIBLE], pág. 47.
4.3. ELECTRICAL CHARACTERISTICS
Electrical control panel for complete process control and to guarantee optimum performance
with minimum power consumption at all times. Containing the following components:
• Circuit breakers.
• Contactors and thermal relay
• Interconnection and ground terminals.
• Card controller and Display.
• Power Supply.
Main electrical data of the machine series:
• OPTIMA:
TABLE 3: MAXIMAL ELECTRICAL DATA [OPTIMA CHILLER], pág. 47.
• MAYA:
TABLE 4: MAXIMAL ELECTRICAL DATA [MAYA REVERSIBLE], pág. 47.
4.4. ELECTRICAL DIAGRAMS
To look up electrical diagrams of the different equipment, consult:
• OPTIMA:
IMAGE 1: ELECTRICAL SCHEME [OPTIMA CHILLER
230 V / 50 Hz / I+N.], pág. 48.
• MAYA:
IMAGE 2: ELECTRICAL SCHEME [MAYA REVERSIBLE – OPTIMA CHILLER 400 V / 50 Hz / III+N.],
pág. 50.
4.5. SIXE
To look up the dimensional data and weight of the product, see:
• OPTIMA:
IMAGEN 3: OPTIMA CHILLER DIMENSIONS, pág. 52.
• MAYA:
IMAGEN 4: MAYA REVERSIBLE DIMENSIONS, pág. 53.
A general rule for the power cable is: section of 1 mm
2
for every 5 amps for cable
lengths of up to 20 meters, although this rule has to be verified and adapted for each
installation and for lengths of more than 20 meters and always in accordance with local
requirements / regulations.
