Front panel
OM226131 Rev. A 15
3.4.3 List of alarms and status
List of alarms List of status
A1 MAINS FAULT S1 AC/DC OK
A2 CHARGER FAULT
A3 RECT FUSE
A5 AC/DC FAULT
A6 INP WR SEQ
A7 BCB OPEN S2 BATT OK
A8 BATT DISCH
A9 BATT AUT END
A10 BATT FAULT
A11 BATT IN TEST
A12 PLL FAULT S5 INV SYNC
A13 INV OUT TOL S3 INV 0K
A14 OVERLOAD S4 INV FEED L0AD
A4 THERM IMAGE
A15 BYP FAULT S6 BYP OK
A16 BYP FEED LO
A17 RETR BLOCK
A18 MBYP CLOSE
A19 OCB OPEN
A20 FANS FAILURE (OPTION)
A21 HIGH TEMP
A22 BYP SWITCH
A23 EPO BUS
A24 CURR STOP
A25 SHORT CIRC
The status shown in this list are always displayed in ascending order when the
STATUS menu is entered, the alarms are shown when they are present and must be
silenced with the buzzer. The alarms remain displayed whilst they are present and they
are automatically stored in the event history memory with date and time.
