5
Rear Panel Interfaces and Indicators
Interfaces on Rear Panel
Name
Colour
Description
ON / OFF
Black
Power button
12V/1A
Black
DC Input Jack
Reset
Black
Factory Reset Button
Long press (>10s) to reset configurations to
factory default.
WAN
Blue
WAN Port
For connection to fibre modem (BTU)
LAN 1
Yellow
LAN Port #1
LAN 2
Yellow
LAN Port #2
LAN 3
Yellow
LAN Port #3
