ASUNA 4200 - Page 9

REF.
DESCRIPTION
QTY
REF.
DESCRIPTION
QTY
H-2
Front end cap-left (triangle)
1
M-3
Adaptor
1
H-3
Front end cap-right (triangle)
1
H-4
Transport wheel
2
S
Main frame set
H-5
Axel of wheel/ Φ12*Φ8*45.5
2
S-1
Main frame
1
H-6
Philip screw/ Φ5*15
8
S-2
Bearing/ 6203Z
2
H-7
Flat washer/ Φ8*Φ16*T1.2
4
S-3
Jump ringΦ17
2
S-4
Belt wheel
1
I
Front post set
S-5
Belt/ J6(440)
1
I-1
Post tube
1
S-6
Sensor seat
1
I-2
Computer middle wire
1
S-7
Lower wire and motor
1
I-3
Philip screw / M5*12
2
S-8
Philip screw / M5*15
2
S-9
Power wire
1
J
Pedal set
S-10
Speed sensor wire
1
J/R
Right pedal
1
S-11
Tension cable
1
J/L
Left pedal
1
S-12
Left chain cover
1
S-13
Right chain cover
1
K
Bottle Holder
1
S-14
Cover cap
1
S-15
Allen bolt / M8*15
4
L
Hardware Package
S-16
Flange screw / M10*1.25*T6.5
2
L-1
Allen bolt / M8*15
10
S-17
Crank cap
2
L-2
Spring washer / Φ8.5
2
S-18
Philip screw/ Φ5*15
3
L-3
Flat washer / Φ8.5*Φ16*T1.5
10
S-19
Out cover
1
L-4
Allen wrench/ L6
1
S-20
Saddle post cover
1
L-5
Spanner wrench
1
S-21
Right crank arm
1
L-6
Open wrench
1
S-22
Saddle post bushing
1
L-7
Quick released knob
1
S-23
Pillar
6
S-24
Philip nail
4
M
Computer set
S-25
Left crank arm
1
M-1
Computer
1
S-26
Cap
1
M-2
Screw/ M5*12
4
Parts List
