ASUNA 4200 - Parts List

REF.
DESCRIPTION
QTY
REF.
DESCRIPTION
QTY
A
Flywheel set
D-3
End cap/ 20*60*T1.5
2
A-1
Flywheel/8kg
1
D-4
Allen bolt /8.8 M8*15
1
A-2
Hex nut/M10
2
D-5
Carriage bolt/ M8*55
1
A-3
Flat washer/ Φ10.5*Φ25*T1.5
2
D-6
Flat washer/ Φ8.5*Φ16*T1.5
1
A-4
Nylon nut/M10
2
D-7
Bushing/ Φ9*Φ13*20
1
D-8
Knob/ M8
1
B
Idle arm set
B-1
Fixing plate of idle wheel
1
E
Handlebar set
B-2
Idle wheel
1
E-1
Handle bar
1
B-3
Spring/ Φ2*Φ16*63/18
1
E-2
Handlebar end cap/ Φ25.4
4
B-4
Bearing/ 6001Z/Φ12*Φ28*8
2
E-3
Handlebar foam-1/ Φ24*Φ30*400
2
B-5
Bushing/ Φ25*Φ12.5*5.3
1
E-4
Handlebar foam-2/ Φ24*Φ30*240
2
B-6
Hex screw/ M6*15
1
E-5
Handle cover-upper
2
B-7
Flat washer/ Φ6.5*Φ16*T1.5
1
E-6
Handle cover-lower
2
B-8
Hex bolt/ M8*22
1
E-7
Pulse wire
2
B-9
Powder bushing/ Φ7.95*Φ13*Φ19*T5.8/F20
1
E-8
Pulse sensor
2
B-10
Flat washer/ Φ8.5*Φ30*T2.0
1
E-9
Philip screw/ Φ3.5*25
2
B-11
Flat washer/ Φ8.5*Φ12*T2.0
1
B-12
Nylon nut/ M8
1
F
Saddle
1
B-13
Flat washer/ Φ8.2*Φ22*T2.0
1
G
Rear stabilizer set
C
Fixing set of flywheel
G-1
Rear stabilizer
1
C-1
Fixing plate of flywheel/ 60*T5.0
1
G-2
Rear end cap-left (triangle)
1
C-2
Fixing plate of flywheel/ 60*T5.0
1
G-3
Rear end cap-right (triangle)
1
C-3
Flat washer/ Φ8.5*Φ16*T1.5
8
G-4
Hex nut/ M10
2
C-4
Allen screw/ 8.8 M8*15
8
G-5
Adjusting bolt/ Φ44*30*M10
2
G-6
Philip screw/ Φ5*15
8
D
Saddle post set
D-1
Saddle post tube
1
H
Front stabilizer set
D-2
Horizontal tube for saddle
1
H-1
Front stabilizer
1
Parts List
