ASUS B85-PLUS
2-27
Enhanced C1 state [Enabled]
[Enabled] Enables enhanced C1 state.
[Disabled] Disables enhanced C1 state.
CPU C3 Report [Enabled]
Allows you to disable or enable the CPU C3 report to OS. Conguration options:
[Enabled] [Disabled]
CPU C6 report [Enabled]
Allows you to disable or enable the CPU C6 report to OS. Conguration options:
[Enabled] [Disabled]
C6 Latency [Short]
Allows you to choose short or long latency for C6. Conguration options: [Short] [Long]
CPU C7 report [CPU C7s]
Allows you to disable or enable the CPU C7 report to OS. Conguration options:
[Disabled] [CPU C7] [CPU C7s]
C7 Latency [Long]
Allows you to choose short or long latency for C6. Conguration options: [Short] [Long]
Package C State Support [Auto]
Allows you to disable or enable the whole C-State package support. Conguration
options: [Auto] [Enabled] [C0/C1] [C2] [C3] [C6] [CPU C7] [CPU C7s]
2.6.2 PCH Conguration
PCI Express Conguration
DMI Link ASPM Control [Auto]
Allows you to control the Active State Power Managemennt on both NB and SB side of
the DMI Link. Conguration options: [Auto] [Enabled] [Disabled]
ASPM Support [Disabled]
Allows you to set the ASPM support. Conguration options: [Disabled] [Auto] [L0s] [L1]
L0sL1].
PCIe Speed [Auto]
Allows you to select the PCI Express port speed. Conguration options: [Auto] [Gen1]
[Gen2]
Intel
®
Rapid Start Technology
Intel
®
Rapid Start Technology [Disabled]
Allows you to enable or disable Intel
®
Rapid Start Technology. Conguration options:
[Enabled] [Disabled]
The following items appear only when you set the Intel
®
Rapid Start Technology to
[Enabled].
Entry on S3 RTC Wake [Enabled]
The system automatically wakes up and set to Rapid Start Technology S4 mode.
Conguration options: [Enabled] [Disabled]
