B85-PLUS specications summary
Specications are subject to change without notice.
Back Panel I/O
ports
1 x PS/2 keyboard port (purple)
1 x PS/2 mouse port (green)
1 x DVI-D port
1 x RGB port
1 x LAN (RJ-45) port
4 x USB 2.0/1.1 ports
2 x USB 3.0/2.0 ports
3 x Audio jacks support 8-channel audio output
Internal
connectors
1 x USB 3.0 connector supports additional 2 USB 3.0 ports
2 x USB 2.0 connectors support additional 4 USB 2.0 ports
2 x SATA 3.0 Gb/s connectors (dark brown)
4 x SATA 6.0 Gb/s connector (yellow)
1 x 4-pin CPU fan connector
2 x 4-pin Chassis fan connectors
1 x Front panel audio connector (AAFP)
1 x System panel connector
1 x S/PDIF connector
1 x COM Header
1 x Clear CMOS jumper
1 x 24-pin EATX power connector
1 x 8-pin ATX 12V power connector
BIOS features 128 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI v2.0, WfM2.0, SM BIOS v2.7,
ACPI v4.0a, Multi-language BIOS, ASUS EZ Flash 2, ASUS CrashFree BIOS
3, My Favorites, Quick Note, Last Modied log, F12 PrintScreen, F3 Shortcut
function, and ASUS DRAM SPD (Serial Presence Detect) memory information
Manageability
Wfm 2.0, DMI 2.0, WOL by PME, PXE
Support DVD Drivers
ASUS utilities
EZ Update
Anti-virus software (OEM version)
Form factor
ATX form factor: 12.0”x 8.2” (30.5cm x 20.8cm)
