Connecting microphone and speakers
This desktop PC comes with microphone ports and speaker ports on both the front and
rear panels. The audio I/O ports located on the rear panel allow you to connect 2-channel,
4-channel, 6-channel, and 8-channel stereo speakers.
Connecting Headphone and Mic
SM.SD.MS-PRO
SM.SD.MS-PRO
D820MT(BM2CE) / D620MT(BM2CF)
D820SF(BP1CE/SD790) / D620SF(BP1CF/SD580)
ASUS Desktop PC
33
