Asus F1A55-M LX3 PLUS R2.0 User Manual

x
Package contents
Check your motherboard package for the following items.
F1A55-M LX3 PLUS R2.0
PCIEX16
PCIEX1_1
PCI1
USB78 USB56
F_PANEL
SPEAKER
KBPWR
USBPW1-4
USBPW5-8
CLRTC
AAFP
ATX12V
EATXPWR
CPU_FAN
CHA_FAN
Lithium Cell
CMOS Power
Super
I/O
ALC
887
AR
8161
EPU
32Mb
BIOS
SB_PWR
22.6cm(8.9in)
AMD
®
A55
DDR3 DIMM_A1 (64bit, 240-pin module) DDR3 DIMM_B1 (64bit, 240-pin module)
SATA3G_4SATA3G_3
SATA3G_1
SATA3G_2
AUDIO
KBMS
LAN_USB12
USB34
18.5cm(7.3in)
VGA
COM1
SOCKET FM1
ASUS F1A55-M LX3 R2.0 Series motherboard 2 x Serial ATA 3.0 Gb/s cables
User Manual
1 x I/O Shield User Guide Support DVD
• If any of the above items is damaged or missing, contact your retailer.
• The illustrated items above are for reference only. Actual product specications may
vary with different models.

Asus F1A55-M LX3 PLUS R2.0 Specifications

General

Form Factor	Micro ATX
Chipset	AMD A55 (Hudson D2)
CPU Socket	FM1
Memory Slots	2 x DIMM
Memory Type	DDR3
Maximum Memory	32GB
Expansion Slots	1 x PCIe 2.0 x16, 1 x PCIe 2.0 x1, 1 x PCI
Storage Interface	4 x SATA 3Gb/s
Audio	Realtek ALC887 8-Channel High Definition Audio CODEC
USB Ports	8 x USB 2.0 (4 on back panel, 4 via headers)
LAN	Realtek RTL8111F, 1 x Gigabit LAN Controller
Video Outputs	VGA, DVI
Power Connector	24-pin ATX
