2-14 ASUS F1A55-M LX3 R2.0 Series
2.4.5 DRAM Timing Control
The sub-items in this menu allow you to set the DRAM timing control features. Use the <+>
and <-> keys to adjust the value. To restore the default setting, type [auto] using the keyboard
and press <Enter>.
Changing the values in this menu may cause the system to become unstable! If this
happens, revert to the default settings.
2.4.6 Hybrid DIGI+ VRMDIGI+ VRM
Load-Line Calibration [Auto]
Load-line is dened by AMD VRM specications, and affects CPU voltage. The CPU
working voltage will decrease proportionally to CPU loading. Higher load-line calibration
would get higher voltage and better overclocking performance, but increases the CPU and
VRM thermal conditions. This item allows you to adjust the voltage range from the following
percentages to boost the system performance: 0% (Regular), 25% (Medium), 50% (High),
75% (Ultra High) and 100% (Extreme). Conguration options: [Auto] [Regular] [Medium]
[High] [Ultra High] [Extreme]
The actual performance boost may vary depending on your CPU specication.
CPU/NB Load-Line Calibration [Auto]
Load-line is dened by Intel VRM spec and affects CPU voltage. The CPU working voltage
will decrease proportionally to CPU loading. Higher value gets a higher voltage and better
overclocking performance, but increases the CPU and VRM thermal. This item allows you to
set this function for better system performance. Conguration options: [Auto] [Regular] [High]
[Extreme]
The actual performance boost may vary depending on your CPU specication.
VRM Fixed Frequency Mode [xxx]
Frequency switching affects the VRM transient response and the thermal component. Higher
frequency gets quicker transient response. Use the <+> and <-> keys to adjust the value. The
values range from 250k Hz to 400k Hz with a 50k Hz interval.
CPU Power Phase Control [Standard]
Allows you to control the power phase based on the CPU’s demands. Conguration options:
[Standard] [Optimized] [Extreme] [Manual Adjustment]
DO NOT remove the thermal module when switching to Extreme and Manual Adjustment.
The thermal conditions should be monitored.

Asus F1A55-M LX3 PLUS R2.0 Specifications

General

Form Factor	Micro ATX
Chipset	AMD A55 (Hudson D2)
CPU Socket	FM1
Memory Slots	2 x DIMM
Memory Type	DDR3
Maximum Memory	32GB
Expansion Slots	1 x PCIe 2.0 x16, 1 x PCIe 2.0 x1, 1 x PCI
Storage Interface	4 x SATA 3Gb/s
Audio	Realtek ALC887 8-Channel High Definition Audio CODEC
USB Ports	8 x USB 2.0 (4 on back panel, 4 via headers)
LAN	Realtek RTL8111F, 1 x Gigabit LAN Controller
Video Outputs	VGA, DVI
Power Connector	24-pin ATX
