Asus F1A55-M LX3 PLUS R2.0 User Manual

DDR3-1333MHz capability
Vendors Part No. Size SS/DS Chip Brand Chip No. Timing Voltage
DIMM socket
support
(Optional)
A* B*
Hynix HMT125U6TFR8A-H9 2GB DS Hynix H5TC1G83TFRH9A -
1.35V(low
voltage)
• •
Hynix
HMT351U6BFR8C-
H9
4GB DS Hynix H5TQ2G83BFRH9C - - • •
Kingmax
FLFD45F-B8KL9
NAES
1GB SS Kingmax KKB8FNWBFGNX-27A - - • •
Kingmax
FLFE85F-C8KF9
CAES
2GB SS Kingmax KFC8FMFXF-DXX-15A - - • •
KINGMAX
FLFE85F-
C8KL9NAES
2GB SS KINGMAX KFC8FNLXF-DXX-15A - - • •
Kingmax
FLFE85F-C8KM9
NAES
2GB SS Kingmax KFC8FNMXF-BXX-15A - - • •
Kingmax
FLFE85F-
B8KL9NEES
2GB DS Kingmax KKB8FNWBFGNX-26A - - • •
KINGMAX
FLFF65F-C8KL9
NEES
4GB DS KINGMAX KFC8FNLXF-DXX-15A - - • •
Kingmax
FLFF65F-C8KM9
NEES
4GB DS Kingmax KFC8FNMXF-BXX-15A - - • •
KINGSTON KVR1333D3N9/1G 1GB SS ELPIDA J1108BDBG-DJ-F 9 1.5V • •
KINGSTON KVR1333D3N9/2G 2GB SS Hynix H5TQ2G83AFRH9C 9 - • •
KINGSTON KVR1333D3N9/2G 2GB DS ELPIDA J1108BFBG-DJ-F 9 1.5V • •
KINGSTON KVR1333D3N9/2G 2GB DS KTC D1288JPNDPLD9U 9 1.5V • •
KINGSTON KVR1333D3N9/2G 2GB DS ELPIDA J1108BDSE-DJ-F 9 1.5V • •
KINGSTON
KHX1333C7
D3K2/4GX(XMP)
4GB(2 x
2GB)
DS - - 7 1.65V • •
KINGSTON
KHX1333C9
D3UK2/4GX(XMP)
4GB(2 x
2GB)
DS - - 9 XMP 1.25V • •
KINGSTON KVR1333D3N9/4G 4GB DS ELPIDA J2108BCSE-DJ-F 9 1.5V • •
KINGSTON KVR1333D3N9/4G 4GB DS Hynix H5TQ2G83AFR - - • •
Micron
MT4JTF12864
AZ-1G4D1
1GB SS Micron OJD12D9LGQ - - • •
Micron
MT8JTF12864
AZ-1G4F1
1GB SS Micron 9FF22D9KPT 9 - • •
Micron
MT8JTF25664
AZ-1G4D1
2GB SS Micron OJD12D9LGK - - • •
Micron
MT16JTF25664
AZ-1G4F1
2GB DS Micron 9KF27D9KPT 9 - • •
Micron
MT16JTF51264
AZ-1G4D1
4GB DS Micron OLD22D9LGK - - • •
PSC AL7F8G73F-DJ2 1GB SS PSC A3P1GF3FGF - - • •
PSC AL8F8G73F-DJ2 2GB DS PSC A3P1GF3FGF - - • •
SAMSUNG M378B2873FHS-CH9 1GB SS SAMSUNG K4B1G0846F - - • •
SAMSUNG M378B5773DH0-CH9 2GB SS SAMSUNG K4B2G0846D - - • •
SAMSUNG M378B5673FH0-CH9 2GB DS SAMSUNG K4B1G0846F - - • •
SAMSUNG M378B5273CH0-CH9 4GB DS SAMSUNG K4B2G0846C - - • •
Super Talent W1333UA1GH 1GB SS Hynix H5TQ1G83TFR 9 - • •
Super Talent W1333X2G8(XMP) 1GB SS - - 8 - • •
Super Talent W1333UB2GS 2GB DS SAMSUNG K4B1G0846F 9 - • •
Super Talent W1333UB4GS 4GB DS SAMSUNG K4B2G0846C - - • •
Super Talent W1333UX6GM 6GB(3x
2GB)
DS Micron 0BF27D9KPT 9-9-9-24 1.5V • •
Transcend JM1333KLN-2G 2GB SS Micron 0YD77D9LGK - - • •
Transcend JM1333KLU-2G 2GB DS Transcend TK243PDF3 - - • •
Transcend TS256MLK64V3U 2GB DS Micron 9GF27D9KPT - - • •
WINTEC 3WVS31333-2G-CNR 2GB DS AMPO AM3420803-13H - - • •
Chapter 1: Product introduction
1-14

Asus F1A55-M LX3 PLUS R2.0 Specifications

General

Form Factor	Micro ATX
Chipset	AMD A55 (Hudson D2)
CPU Socket	FM1
Memory Slots	2 x DIMM
Memory Type	DDR3
Maximum Memory	32GB
Expansion Slots	1 x PCIe 2.0 x16, 1 x PCIe 2.0 x1, 1 x PCI
Storage Interface	4 x SATA 3Gb/s
Audio	Realtek ALC887 8-Channel High Definition Audio CODEC
USB Ports	8 x USB 2.0 (4 on back panel, 4 via headers)
LAN	Realtek RTL8111F, 1 x Gigabit LAN Controller
Video Outputs	VGA, DVI
Power Connector	24-pin ATX
