Asus P11C-C/4L User Manual

4-29
P11C-C/4L
PEG 0:1:3
PEG3 Slot Power Limit Value [75]
Settheupperlimitonpowersuppliedbyslot.Usethe<+>or<->toadjustthevalue.
The values range from 0 to 255.
PEG3 Slot Power Limit Scale [1.0x]
AllowsyoutoselectthescalefortheSlotPowerLimitValue.
Congurationoptions:[1.0x][0.1x][0.01x][0.001x]
PEG3 Physical Slot Number [3]
Allows you to set the physical slot number attached to this Port. The number has to be
globally unique within the chassis. Usethe<+>or<->toadjustthevalue.Thevalues
range from 0 to 8191.
PEG3 Hotplug [Disabled]
Allows you to enable or disable PCI Express Hot Plug.
Congurationoptions:[Disabled][Enabled]
PEG0 Max Payload size [Auto]
Allows you to select the PEG0 Max Payload size.
Congurationoptions:[Auto][128][256TLP]
VT-d [Enabled]
Allows you to enable or disable VT-d capability.
Congurationoptions:[Disabled][Enabled]
CRID Support [Disabled]
Allows you to enable or disable CRID control for Intel SIPP.
Congurationoptions:[Disabled][Enabled]
Above 4GB MMIO BIOS Assignment [Disabled]
Allows you to enable or disable above 4 GB memory mapped IO BIOS assignment. This is
enabled automatically if the aperture size is set to 2048MB.
Congurationoptions:[Disabled][Enabled]
The following item appears only when you set the VT-d to [Enabled].
X2APIC Opt Out [Disabled]
Allows you to enable or disable X2APIC Opt Out.
Congurationoptions:[Disabled][Enabled]
